IC AT24C08AN-PU27 DIP-8 EEPROM 8KBIT COM24

DescriptionThe AT24C08A provides 8192 bits of serial electrically erasable and programmable read only memory (EEPROM) organized as 1024 words of 8 bits each. The device is optimized for use in many industrial and commercial applications where low power and low voltage operation are essential. The AT24C08A is available in space saving 8-pin PDIP, 8-pin, 14-pin SOIC, and 8-pin TSSOP packages and is accessed via a 2-wire serial interface. In addition, the entire 24C0x family is available to 5.5V) and to 5.5V) versions.AT24C08A, 8K SERIAL EEPROM  is internally organized with 4 blocks of 256 pages of 4-bytes each. Random word addressing requires a 10 bit data word address. Package includes: 1×AT24C08Features• Extended Power Supply Voltage Single Vcc for Read and Programming (Vcc = 2.7 V to 5.5 V)Low Power (Isb = 2µa @ 5.5 V)I²C Bus, 2-Wire Serial InterfaceSupport Byte Write and Page Write (16 Bytes)Automatic Page write Operation (maximum 10 ms) Internal Control Timer Internal Data Latches for 16 BytesHigh Reliability CMOS Technology with EEPROM Cell Endurance : 1,000,000 Cycles Data Retention : 100 YearsSchmitt Trigger, Filtered Inputs for Noise SuppressionBidirectional Data Transfer Protocol
